Recently I have been involved as the Integration Architect and tech lead for a project to integrate between MS Dynamics 356 AX/CRM and 3rd party systems.
One of the challenges was to provide single endpoints for internal systems calling web services outside of the organisation that utilised OAuth2.0. This is where a consumer normally has to call an OAuth token endpoint first and then append the token to the request before calling the actual web service.
By using APIM as a proxy and policies in APIM, I managed to achieve the goal of providing a single URL endpoint for the consumer. The policy initially gets the token from the authorisation endpoint, caches the token and then passes the token to the web service being called. This process is known as fragment caching, where parts of the responses are cached for subsequent requests. Also by caching the bearer part of the token improved the performance significantly for subsequent calls.
Below were the steps I used to add a web API to create transfers orders in Dynamics AX and a policy using the Azure APIM management portal.
1. First create the properties for the oAuth clientId and client secret. A good tip is to prefix the property name and set the Tags with the name of the API you are calling. This helps latter on when you have multiple properties to manage.
The Properties page should look like something like below after adding your custom properties:
2. Next, go to the API’s page to either add or import the API’s definition you are calling. Here I am just going to add the API manually by first entering the name, API endpoint address and the public facing URL suffix. Remember to add it to an existing product.
3. After the API has been created we will then add the operations. For this demo I will just add one operation to create a transfer order.
4. Now that the API we wish to call has been added to the APIM service we can finally pay our attention to creating a policy which does the background task of obtaining the OAuth token. Here I will setup a policy on the CreateTransferOrder operation of the Web API. Once selected, click the ADD POLICY button to begin creating the policy from the template.
5. The “<inbound>” policy section is applied to the incoming request before forwarding the request to the backend service. This is where we will check the cache for the authorisation token and if no hit, then we call the OAuth token endpoint to obtain a token.
1: <inbound>
2: <cache-lookup-value key="token-{{Dev-Web1-ClientId}}" variable-name="bearerToken" />
3: <choose>
4: <when condition="@(!context.Variables.ContainsKey("bearerToken"))">
5: <send-request mode="new" response-variable-name="oauthResponse" timeout="20" ignore-error="false">
6: <set-url>https://login.microsoftonline.com/xxxxxx.onmicrosoft.com/oauth2/token</set-url>
7: <set-method>POST</set-method>
8: <set-header name="Content-Type" exists-action="override">
9: <value>application/x-www-form-urlencoded</value>
10: <!-- for multiple headers with the same name add additional value elements -->
11: </set-header>
12: <set-body>@("grant_type=client_credentials&client_id={{Dev-Web1-ClientId}}&client_secret={{Dev-Web1-ClientSecret}}&resource=https%3A%2F%2Fxxxx.xxxxx.ax.dynamics.com")</set-body>
13: </send-request>
14: <set-variable name="accessToken" value="@((string)((IResponse)context.Variables["oauthResponse"]).Body.As<JObject>()["access_token"])" />
15: <!-- Store result in cache -->
16: <cache-store-value key="token-{{Dev-Web1-ClientId}}" value="@((string)context.Variables["AccessToken"])" duration="3600" />
17: </when>
18: </choose>
19: </inbound>
Lets go through the key points of this definition below.
- Line 2: – Assigns the value in cache to the context variable called “bearerToken”. On first entry, the cache value will be null and the variable will not be created. Note I am adding the ClientId as part of the cache key name to keep it unique. Property values are accessed by surrounding the key name with double braces. eg {{myPropertyName}}
- Line 4: – Checks if the context variable collection contains a key called “bearerToken” and if not found executes the code between the opening and closing “<when>” XML elements.
- Line 5: – Initiates the request to the OAuth endpoint with a response timeout of 20 seconds. This will put the response message into the variable called “oauthResponse”
- Line 6: – Is where you set the URL to send the request to. In this scenario I am using the Azure AD OAuth token endpoint below as our STS service: https://login.microsoftonline.com/xxxxxx.onmicrosoft.com/oauth2/token
- Line 12: – This is where you define the body payload for the request and this is defined as a typical client credentials grant type payload. Here I am getting the values for the client Id and secret from the user definable properties set in the Properties page. The resource parameter is just hardcoded to the Urlencoded resource URL of the API but can also parameterised.
<set-body>@(“grant_type=client_credentials&client_id={{Dev-Web1-ClientId}}&client_secret={{Dev-Web1-ClientSecret}}&resource=https%3A%2F%2Fxxxx.xxxxx.ax.dynamics.com”)</set-body>
- Line 14: – Casts the response as a JSON object to allow the retrieval of the “access_token” value using an indexer and assigns it to the context variable “accessToken”.
- Line 16: – Is where we add the contents of the variable “accessToken” into cache for a period of 3600 seconds.
6. Now that the “<inbound>” section has been completed, we can look at the “<backend>” section of the policy. This is where the policy forwards your request to the backend web service as defined in the API configuration page.
1: <backend>
2: <send-request mode="copy" response-variable-name="transferWSResponse" timeout="20" ignore-error="false">
3: <set-method>POST</set-method>
4: <set-header name="Authorization" exists-action="override">
5: <value>@("Bearer " + (string)context.Variables["bearerToken"])</value>
6: </set-header>
7: <set-header name="Ocp-Apim-Subscription-Key" exists-action="delete" />
8: <set-header name="Content-Type" exists-action="override">
9: <value>application/json</value>
10: </set-header>
11: </send-request>
12: </backend>
Lets go through this section as before.
- Line 2: – Creates the request to the backend web service. Here we are placing the response from the web service into the variable called “transferWSResponse”.
- Line 4: – Is the creating the “Authorization” header to be sent with the request.
- Line 5: – Adds the bearer token value from the context variable “bearerToken” the authorisation header.
- Line 7: – Removes the APIM subscription from being forwarded to the backend web service.
7. Now we need to return the response message from the backend web service to the caller. This is done in the “<outbound>” policy section. Here we just simply return the value of the variable “transferWSResponse” back to the caller.
1: <outbound>
2: <return-response response-variable-name="transferWSResponse">
3: </return-response>
4: <base />
5: </outbound>
That’s the whole policy defined which will call the OAuth endpoint the get the token and cache it for subsequent calls.
Using the tracing feature in APIM, when the first request is made, the cache will be null and the variable will not be set as shown below.
The next trace shows any subsequent requests will hit the cache and set the context variable to the bearer token until it expires.
One important note about retrieving data from cache is its an out-of-process call and can add tens of milliseconds onto a request.
Working with the APIM polices can make a huge impact on your API development efforts as logging and access management can be off-loaded using the polices available in APIM. A full list of expressions used in polices can be found here: https://docs.microsoft.com/en-us/azure/api-management/api-management-policy-expressions
